Mechanical Dimensions 747 x 525 x 347 mm (29.4 x 20.7 x 13.7") Weight 3.2 kg (7.1 lb) Enclosure material Aluminum alloy, UV-stabilized polycarbonate Mount material UV-stabilized polycarbonate Mount Integrated pole mount (included) Pole compatibility: Ø35 to 60 mm (Ø1.4 to 2.4") Wind loading 1100 N at 200 km/h (247.29 lbf at 125 mph) Weatherproofing IPX6 Hardware Networking interface (1) GbE RJ45 port Power method Passive PoE 2-pair (4, 5 ; 7, 8-) Power supply 24V, 0.5A gigabit PoE adapter (Included) Supported voltage range 22—27V DC Max. power consumption 9W RF connections Internal LEDs Power/Ethernet Button Factory reset Ambient operating temperature -40 to 55° C (-40 to 131° F) Ambient operating humidity 5 to 95% non-condensing Certifications FCC, IC, CE Software Modes PtMP CPE, PtP* *1.5.1 and later 1.5.x series firmware. Services SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog Utilities airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation Auto distance adjustment Yes Auto power adjustment Yes Network Bridge/Router* mode *Router mode is available in PtMP CPE mode only. Security Yes Statical reporting Yes Management interface Bluetooth management for easy setup over UISP App WEB UI Minimum software requirements Any modern web browser iOS™ or Android™ based smartphone System Maximum throughput 900 Mbps* *FW version 2.3.0 and later. Encryption WPA2-PSK (AES) Uplink/downlink ratio 25/75, 33/67, 50/50 RF Operating frequency* 5.15 to 5.95 GHz *Depends on regulatory region. Max. conducted TX power 25 dBm Channel bandwidth 10/20/30/40/50/60/80/100 MHz* *FW version 2.3.0 and later. Antenna gain 29 dBi Isolation 20 dB Beamwidth HPOL: 3 dB: 5.5°, 6 dB: 7.5° VPOL: 3 dB: 5.5°, 6 dB: 7.5° Elevation: 3 dB: 5.5°, 6 dB: 7.5° Electrical downtilt 0°
